This was the wiring diagram that I did in the very early spring. It is still the plan to use this as the basis of the wiring for the boat.
At this time, all circuits function and the boat is pretty simple and clean. Several issues exsist though.
(This is low on the priority list - put off till spring)
1. Glass fuses hidden behind the stairs boat. I want to move the wiring out so that I am able to access fuses and to be easily be able to add or remove items. All I have at the moment is the original switch panel. So I want a proper panel and associated controls and accessories.
2.VHF is in a poor spot, it is also very old, but working. Thinking to replace for some of these spiffy $99 units out there.
3. AC circit needs to be done, and that is one I am KISSing.. I am not going to use a breaker in the boat. I will never have enough stuff in the G26 AC wise that I need an internal breaker. I will wire a GFI as the first outlet in the boat, and then any others will follow (GFI in a series circuit will protect everything down line from it.)
I will be tackling this in order of #3 the AC first - This will make the circuit safer and allow me to do other work over the winter in the boat.
